Datavideo DAC-9P HDMI - HD/SD-SDI konverter
A Datavideo DAC-9P egy robosztus burkolatú, PAL / NTSC kompatibilis HDMI - HD/SD-SDI konverter
1 x HDMI bemenettel és 2 x SDI (HD/SD SDI) kimenettel.
Alternatíva
Részletes leírás
Jellemzők
Specifikáció
Csomag tartalma
Küldés
Értékelések
Datavideo DAC-9P HDMI - HD/SD-SDI konverter
- Input: 1 X HDMI
- Output: 2 x SDI (HD / SD SDI)
- Enables long cable runs
- Rugged case design
- Audio can be embedded within SDI output signal
- PAL / NTSC Compatible
- Tripod Mount via Velcro straps (Supplied)
- DC 12V Operation
- Video output format is the same as the input format, so "what goes in, comes out"
- Video input formats:
- 1080P59.94, 1080P60, 1080P50, 1080P30, 1080P29.97, 1080P25, 1080P24, 1080P23,98
- 1080i60, 1080i59,94, 1080i50
- 720P59,94, 720P60, 720P50
- 525i, 625i
•Heavy duty design, robust metal casing
•Low power consumption (30 ~ 50% less than regular converters)
•Low heat dissipation, ideal for long hour operation in normal ventilated environment
•Support wide range of 3G video formats including 1080p 50/59.94/60Hz (DAC-8P/9P/50S/60/70)
•Support YUV and RGB color space (DAC-8P/9P/70)
•Can be rackmounted using optional RMK-2 2RU Rackmount Kit
•Can be used with DAC accessories: MB-4 DAC Series Battery Holder, and MB-5 DAC Series Tripod Mount
•Low power consumption (30 ~ 50% less than regular converters)
•Low heat dissipation, ideal for long hour operation in normal ventilated environment
•Support wide range of 3G video formats including 1080p 50/59.94/60Hz (DAC-8P/9P/50S/60/70)
•Support YUV and RGB color space (DAC-8P/9P/70)
•Can be rackmounted using optional RMK-2 2RU Rackmount Kit
•Can be used with DAC accessories: MB-4 DAC Series Battery Holder, and MB-5 DAC Series Tripod Mount
- 1 x DAC-9P 1
- 1 x Switching Adaptor DC 12V 500mA
- 1 x DAC-9P Quick Start Guide
| Conversion | HDMI to 3G/HD/SD-SDI |
|---|---|
| Video inputs | 1x HDMI |
| Loop Through | N/A |
| Video Outputs | 2x 3G/HD/SD-SDI with embedded Audio |
| Audio inputs | 2CH HDMI Audio embedded |
| Audio Outputs | 2CH SDI Audio embedded |
| Supported Video Input Format | 480i (NTSC), 576i (PAL), 720p (50/59.94/60Hz), 1080i (50/59.94/60Hz), 1080p (23.98/24/25/29.97/ 30/50/59.94/60Hz) |
| Output Resolutions | Automatically matches the SD, HD and 3G HDMI video input |
| Equalizer | N/A |
| Reclock | N/A |
| SDI Cable Drive | Yes |
| Power | DC 12V, 5 watts |
Nem található bejegyzés
72.700 Ft
