Blackmagic Design Micro Studio Camera 4K G2
Blackmagic Design Micro Studio Camera 4K G2
• 12G-SDI be- és kimenet, HDMI kimenet
• MFT-Mount
• Kameravezérlés SDI-n, HDMI-n vagy USB-n keresztül
• Program és Talkback SDI-on keresztül, Tally
• Beépített mikrofonok, színkorrektor
• USB-C külső meghajtókhoz és Ethernet-vezérléshez
• 3,5 mm-es audio bemenet
• Canon LP-E6 akkumulátor foglalat
• 12V AC tápegység nemzetközi aljzatadapterekkel
• Porvédő sapka
• Jótállás: 1 év
Blackmagic Design Studio Camera 4K G2 Specifications |
|||
| Camera Features | |||
Effective Sensor Size |
17.78mm x 10mm (Four Thirds) | ||
Lens Mount |
Active MFT Mount. | ||
Lens Control |
Iris, focus, zoom on supported lenses. | ||
Dynamic Range |
13 Stops. | ||
Dual Native ISO |
0dB and 18dB gain. | ||
Sensitivity at 0dB Gain |
f11 with 2160p59.94. f12 with 2160p50. at 2,000 lux with 89.9% reflectance. |
||
Signal to Noise Ratio |
63dB for 2160p. | ||
Shooting Resolutions |
3840 x 2160 (Ultra HD) up to 60 fps. | ||
Frame Rates |
23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 frames per second.Off-speed frame rates up to 60 fps in Ultra HD. |
||
Focus |
Auto focus available using compatible lenses. | ||
Metadata Support |
Automatically populated lens data from electronic Micro Four Thirds lenses. Automatic recording of camera settings, motion sensor data plus slate data such as project, scene number, take and special notes. A 3D LUT can also be embedded in metadata of Blackmagic RAW files. | ||
Mounting Options |
1 x 1/4 inch (top), 3 x 1/4 inch (bottom). |
||
| Connection | |||
SDI Video Inputs |
1 | ||
SDI Video Outputs |
1 | ||
SDI Rates |
3G, 6G, 12G. | ||
HDMI 2.0 Video Outputs |
1 | ||
HDMI Video Outputs |
1 x HDMI Type A output. HDMI output is always HD, up to 1080p60. |
||
Analog Audio Output |
1 x 3.5mm Stereo Input. Can also be used for Timecode input. | ||
Reference Input |
Program SDI Input on camera. | ||
SDI Audio Output |
2 channels of program audio embedded in 3G/6G/12G-SDI. | ||
HDMI audio Outputs |
2 channels 48 kHz and 24‑bit. | ||
| Remote Control | Remote camera control over SDI, HDMI or USB Ethernet with suitable adapter. | ||
| Computer Interface | 1 x USB Type‑C 3.1 Gen 1 (up to 5Gb/s) expansion ports for external recording and focus / zoom demand connection. Software updates using USB‑C Port. | ||
| Audio | |||
| Microphone | Integrated stereo microphone. | ||
| Built in Speaker | None | ||
| Standards | |||
| SD Video Standards | None | ||
| HD Video Standards | 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080i50, 1080i59.94, 1080i60 |
||
| Ultra HD Video Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60 | ||
| SDI Compliance | SMPTE 292M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081‑1, SMPTE 2081‑10, SMPTE 2082‑1 and SMPTE 2082‑10. | ||
| SDI Audio Sampling | Television standard sample rate of 48 kHz and 24‑bit. | ||
| Media | |||
| Media | 1 x USB-C 3.1 Gen 1 expansion ports for external media for recording Blackmagic RAW. | ||
| Media Format | Can format media to ExFAT (Windows/Mac) or HFS+ (Mac) file systems. | ||
| Supported Codecs | |||
| Codecs | Blackmagic RAW Constant Bitrate 3:1, Blackmagic RAW Constant Bitrate 5:1, Blackmagic RAW Constant Bitrate 8:1, Blackmagic RAW Constant Bitrate 12:1, Blackmagic RAW Constant Quality Q0, Blackmagic RAW Constant Quality Q1, Blackmagic RAW Constant Quality Q3, Blackmagic RAW Constant Quality Q5 |
||
| Storage Features | |||
| Storage Type | 1 x USB‑C 3.1 Gen 1 expansion ports for external media. | ||
| Recording Formats | Blackmagic RAW 3:1, 5:1, 8:1, 12:1, Q0, Q1, Q3 and Q5 in Ultra HD 3840 x 2160 at the selected frame rate. | ||
| Storage Rates | Storage rates based on 30 frames per second.
3840 x 2160 (Ultra HD) Blackmagic RAW 3:1 - 127 MB/s |
||
| Control | |||
| External Control | 5 control buttons including Set, Up, Down, Menu, and Power. Blackmagic Zoom Demand and Blackmagic Focus Demand for controlling your camera and lens from tripod handles. Blackmagic Control Protocol over SDI and HDMI for external control when used with a compatible ATEM switcher with ATEM Software Control or ATEM Camera Control Panel. Includes control of some camera settings, focus, iris and zoom with compatible lenses, color corrector, tally and record start and stop to external media via USB expansion port. Camera Control REST API over USB Ethernet for external control via HTTP when used with REST client applications such as Postman. |
||
| Network Management | |||
| NTP | Network time protocol support allows you to sync the time on your camera, whenever connected to a network with any NTP server of your choice. | ||
| Web Media Manager | Using a browser connected over Ethernet, web media manager allows you to access, browse, download and delete files from any drive connected to the camera. | ||
| FTP | Download files from any drive attached to your camera using FTP. | ||
| SMB | File sharing using SMB | ||
| Color Corrector | |||
DaVinci YRGB |
|||
| Tally | |||
| Live Tally Indicator | 1 x front facing for talent, | ||
| Power Requirements | |||
| Power Supply | 1 x External 12V DC 36W power supply. | ||
| Power Inputs | 1 x 12V DC locking 5.5 mm barrel connector. | ||
| Power Usage | 18 ‑ 25 W. | ||
| Optional Accessories | |||
Blackmagic Focus Demand |
|||
| Environmental Specifications | |||
| Operating Temperature | 0° to 40° C (32° to 104° F) | ||
| Storage Temperature | -20° to 45° C (-4° to 113° F) | ||
| Relative Humidity | 0% to 90% non-condensing | ||
