Datavideo HS-1600T Mark II 4-Ch Video Streaming Studio
• Beépített 17.3" 1080p TFT LED Monitor
• 1x HDMI és 3x HDBaseT bemenet
• 1x HDMI és 2x HDMI program kimenet
• 1x HDBaseT kimenet, 1x Streaming kimenet
• Valós idejű H.264 Web Streaming Encoder
• PiP, Wipe, Mix, Fade & Upstream kulcsok
• Beépített kameravezérlés: max. 3 Datavideo PTZ kamera
• 2RCA és XLR audio bemenet
• Tally
• Rögzítés SD-kártyákra
• 1x HDMI és 3x HDBaseT bemenet
• 1x HDMI és 2x HDMI program kimenet
• 1x HDBaseT kimenet, 1x Streaming kimenet
• Valós idejű H.264 Web Streaming Encoder
• PiP, Wipe, Mix, Fade & Upstream kulcsok
• Beépített kameravezérlés: max. 3 Datavideo PTZ kamera
• 2RCA és XLR audio bemenet
• Tally
• Rögzítés SD-kártyákra
• Datavideo HS-1600T Mark II 4-Ch Video Streaming Studio
• 56V-os tápegység
• AC tápkábel
• 3x Cat 6 Ethernet kábel (55")
• Jótállás: 1 év (termékregisztráció esetén 3 év)
• 56V-os tápegység
• AC tápkábel
• 3x Cat 6 Ethernet kábel (55")
• Jótállás: 1 év (termékregisztráció esetén 3 év)
Datavideo HS-1600T Mark II Specification |
|||
Model Number |
HS-1600T MARK II |
||
Video Standard |
HD& SD |
||
Video Format |
1080p 50/59.94/60Hz 1080i 50/59.94/60Hz 720p 50/59.94/60Hz 576i/p 50Hz 480i/p 59.94Hz |
||
Input Routable / Crosspoint |
----- |
||
Video Input |
3 x HDBaseT 1 x HDMI |
||
Computer Graphic Interface |
1 via HDMI |
||
Computer Graphic Interface |
Yes |
||
Down-converted Output |
Yes |
||
Down-converted Output |
---- |
||
Video Output |
3x HDMI PGM |
||
Analogue Audio Input | 2x Balanced XLR 1x Stereo RCA (L/R) De-embedded Digital Audio |
||
Analogue Audio Output | 1x Stereo headphone | ||
Digital Embedded Audio Support |
Input 2 channels, Output 2 channels | ||
Audio Delay Calibration |
------ | ||
A+V Switching |
------ | ||
USK | 1x USK support Lumakey | ||
DSK | ----- | ||
Picture in Picture |
1 | ||
Logo Insertion |
-------- | ||
Title Creator |
--------- | ||
Built-in Audio Mixer |
Yes, 4 channels | ||
Built-in Monitor Display |
17.3” HD TFT LED backlit, 1920x1080 pix | ||
Camera Control |
--------- | ||
Streaming | |||
Streaming | H.264 / AVC, Main/ High Profile Configurable Bit-rate up to 10Mbps |
||
Streaming Audio Encode | AAC-LC Configurable bit rate range from 32Kbps to 384Kbps Sample rate: 48KHz, 16bi |
||
Streaming Protocol | TS over TCP/UDP (unicast & multicast) RTSP over HTTP/TCP/UDP (RTSP Elementary Streaming) RTMP/RTMPS (Publish) HLS SRT |
||
Streaming Control | Web browser UI for configuration and control Socket commands | ||
Recording File System |
FAT, exFAT, NTFS | ||
Recording File Format | MP4 | ||
Streaming & Recording Setting Control | Web UI for system configuration and control | ||
Others | |||
Special Features |
Built-in camera controller | ||
Dimension (LxWxH) |
455 x 355 x 134 mm | ||
Weight | 17.2 Lbs (7.8 kg), Reinforce Plastic Case | ||
Power | DC 48V, 4.16A | ||
Operating Temp. Range |
0~40 °C | ||
What's in the Box |
1 x HS-1600T MARK II Product 1 x AD Switch DC 56V with AC Cord 3 x Ethernet Cable |
