Datavideo Showcast 100 4K Streaming Studio
• Bemenet: 4-ch HDMI
• 14"-os érintőképernyős kijelző
• Érintőképernyős nyomógombok
• Digitális hangkeverő
• Multiview kimenet HDMI-n keresztül
• Live streaming USB-n keresztül
• 14"-os érintőképernyős kijelző
• Érintőképernyős nyomógombok
• Digitális hangkeverő
• Multiview kimenet HDMI-n keresztül
• Live streaming USB-n keresztül
• Datavideo Showcast 100 4K Streaming Studio
• 1x AD Switcher DC 12V AC kábellel
• Jótállás: 1 év
• 1x AD Switcher DC 12V AC kábellel
• Jótállás: 1 év
Datavideo Showcast 100 4K Streaming Studio Specification |
|||
Model Number |
SHOWCAST 100 |
||
Video Standard |
4K & HD |
||
Video Format |
Input: 3840x2160p: 60/59.94/50/30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 VGA, XGA (1024 x 768), SXGA (1280 x 1024), UXGA (1600 x1200), WUXGA (1920 x 1200) Output: |
||
Video Processing |
4K60 YUV4:4:4 8bit, YUV 4:2:2 8/10bit, YUV 4:2:0 8bit, RGB 4:4:4 8bit 4K30 YUV4:4:4 8/10/12bit, YUV 4:2:2 8/10/12bit, YUV 4:2:0 8bit, RGB 4:4:4 8/10/12bit HD YUV4:4:4 8/10/12bit, YUV 4:2:2 8/10/12bit, RGB 4:4:4 8/10/12bit |
||
Input Routable / Crosspoint |
N/A |
||
Video Input |
4 x HDMI 2.0 |
||
Computer Graphic Interface |
4 via HDMI |
||
Video Output |
3 x HDMI 2.0 for PGM 1 x HDMI for CG Preview |
||
Down-converted Output |
Yes |
||
| Built-in Multi-view Monitoring Out |
On 14" Touch Pane |
||
| Analogue Audio Input | 2 x 3 Pin XLR / 1/4” (6.3mm) Combo Socket 1 x Stereo RCA set (L/R) Audio Input Switch: Stereo / Mono |
||
| Analogue Audio Output | 1 x Stereo RCA set (L/R) 1 x Stereo headphone (Mini Jack with volume control) |
||
| Digital Embedded Audio Support | Digital Embedded Audio Support | ||
| Audio Delay Calibration |
Up to 200ms | ||
| A+V Switching |
Yes | ||
| Title Creator |
Web GUI | ||
| USK |
Lumakey | ||
| Picture in Picture |
1 | ||
| Effects |
Seamless Cut, WIPE, Mix | ||
| Sync / Reference In/Out |
Built-in Genlock (internal) | ||
| Tally Output |
D-Sub -15 Male connector | ||
| PC Remote Control |
Web browser UI for configuration and control Socket commands |
||
| Camera Control |
DVIP/ RS-422/ RS-232 | ||
| Built-in Audio Mixer |
Yes | ||
| Storage |
1 x SD Card Slot Supports SD, SDHC and SDXC card (UHS-I) (Class 10 above) |
||
| Recording File System |
FAT, NTFS, exFAT | ||
| Recording File Format |
MP4 | ||
| Video Encode |
H.264 / AVC, Main/ High Profile Record Only: Up to 16Mbps (1080p 50/60) Stream Only: Up to 10Mbps (1080p 50/60) Rec and Stream: Up to 10Mbps (1080p 25/30) Rec and Stream: Up to 36Mbps (1080p50/60), Dual Stream |
||
| Audio Encode |
AAC-LC Configurable bit rate range from 32Kbps to 384Kbps Sample rate: 48KHz, 16bit |
||
| Streaming Protocol |
TS over TCP/UDP (unicast & multicast) RTSP over HTTP/TCP/UDP (RTSP Elementary Streaming) RTMP (Publish) |
||
| Firmware Update |
USB | ||
| Special Features |
14.0" Touchscreen Display | ||
| Chassis |
Unibody | ||
| Dimension (LxWxH) |
437.6 x 330.5 x 96.5mm | ||
| Weight | 5.4 Kg | ||
| Power | DC 12V 82W | ||
| Operating Temp. Range |
0~40 °C | ||
| What's in the Box |
1 x Showcast 100 product 1 x AD Switch DC 12V with AC Cord |
||
Nem található bejegyzés
64.221 Ft
